Cyber Security Challenge Germany
2026
IntroForensics3
A ransomware variant messed up image files. Recover the image by understanding the file format.
Forensics
116 points
Walkthrough
We get a file called
intro-forensics-3
.
At first, file
does not recognize it:file ./intro-forensics-3
./intro-forensics-3: data
Since the challenge talks about messed up image files, I started by checking for familiar signatures and embedded data.
binwalk
finds compressed zlib data:binwalk -e ./intro-forensics-3
DECIMAL HEXADECIMAL DESCRIPTION
--------------------------------------------------------------------------------
622927 0x9814F Zlib compressed data, best compression
Looking closer at the bytes, the file is still structured like a PNG. It has normal PNG chunks such as
IHDR
, cHRM
, bKGD
, many IDAT
chunks, and IEND
.
The problem is that the IDAT
chunks are not in the right order, and their CRC fields have been repurposed as order indices.So we can parse the chunks, sort the
IDAT
chunks by that value, and write a repaired PNG.
The useful part of the recovery script looks like this:import struct
import zlib
def extract_chunks(filename):
with open(filename, "rb") as f:
data = f.read()
chunks = []
offset = 8
while offset < len(data):
length = int.from_bytes(data[offset:offset+4], "big")
chunk_type = data[offset+4:offset+8]
chunk_data = data[offset:offset+8+length+4]
crc_value = int.from_bytes(data[offset+8+length:offset+8+length+4], "big")
chunks.append((chunk_type, crc_value, chunk_data))
offset += 8 + length + 4
return chunks
chunks = extract_chunks("intro-forensics-3")
ihdr = [data for typ, _, data in chunks if typ == b"IHDR"][0]
chrm = [data for typ, _, data in chunks if typ == b"cHRM"][0]
bkgd = [data for typ, _, data in chunks if typ == b"bKGD"][0]
iend = [data for typ, _, data in chunks if typ == b"IEND"][0]
idats = sorted(
[(crc, data) for typ, crc, data in chunks if typ == b"IDAT"],
key=lambda x: x[0],
)
with open("recovered.png", "wb") as f:
f.write(b"\x89PNG\r\n\x1a\n")
def write_chunk(chunk):
typ = chunk[4:8]
data = chunk[8:-4]
real_crc = zlib.crc32(typ + data) & 0xffffffff
f.write(chunk[:-4] + struct.pack(">I", real_crc))
for chunk in [ihdr, chrm, bkgd]:
write_chunk(chunk)
for _, chunk in idats:
write_chunk(chunk)
write_chunk(iend)
Opening the recovered image shows the flag:
CSCG{space_space_spaaaace_space!!!}
